Catalyst 9117AXI Acces Point, Wi-Fi, Embedded Wireless Controller, Domanin E
Cisco Catalyst 9117AX. Maximum data transfer rate: 5000 Mbit/s, LAN data rates: 100,1000,2500,5000 Mbit/s, Frequency band: 2.412 – 2.462, 5.18 – 5.32, 5.5 – 5.7, 5.745 – 5.865 GHz. Security algorithms: AES, EAP-, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA, WPA2. Placement: Wall, Product colour: , Certification: IEC 60950-1 EN 60950-1 AS/NZS 60950.1 UL 60950-1 CAN/CSA-C22.2 No. 60950-1 UL 2043 Class III…. Antenna type: Internal, Antenna direction type: Omni-directional, Antenna gain level (max): 6 dBi. Flash memory: 1024 MB, Internal memory: 2048 MB
The Cisco® Catalyst® 9117 Access Points are the next generation of enterprise access points. They are resilient, secure, and intelligent.
Hyperconnectivity with steady performance in demanding environments. Exponential growth of Internet of Things (IoT) devices and next-generation applications. Advanced persistent security threats. All of these require a wireless network that provides resiliency and superior connectivity, integrated security with advanced classification and containment, and hardware and software innovations to automate, secure, and simplify networks. Updating your wireless infrastructure to one that will meet these needs is paramount for today’s digital business. The new generation of Cisco Catalyst 9100 Access Points, with high-performance Wi-Fi 6 (802.11ax) capabilities and innovations in RF performance, security, and analytics, enables end-to-end digitization and helps accelerate the rollout of business services by delivering beyond Wi-Fi.
| Weight | 1.58 kg |
|---|---|
| Flash memory | 1024 MB |
| Product Condition | New Retail |
| Internal memory | 2048 MB |
| USB 2.0 ports quantity | 1 |
| pa_i_ethernetlanrj4_2312_1 | 1 |
| Weight | 1.4 kg |
| Power over Ethernet (PoE) | Yes |
| Operating altitude | 0 – 3000 m |
| Operating relative humidity (H-H) | 10 – 90% |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -30 – 70 °C |
| Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
| Security algorithms | AES, EAP-FAST, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, WPA, WPA2 |
| Certification | IEC 60950-1 |
| LED indicators | Yes |
| Frequency band | 2.412 – 2.462, 5.18 – 5.32, 5.5 – 5.7, 5.745 – 5.865 GHz |
| Antenna gain level (max) | 6 dBi |
| Antenna type | Internal |
| Web-based management | Yes |
| Non-operating altitude | 0 – 4572 m |
| Height | 49.3 mm |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz |
| Depth | 220 mm |
| Width | 220 mm |
| Product colour | White |
| Placement | Wall |
| Maximal-Ratio Combining (MRC) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Data unit aggregation | A-MPDU, A-MSDU |
| Dynamic Frequency Selection (DFS) | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Antenna direction type | Omni-directional |
