NWA110AX, Triple Pack 802.11ax, exclude Power Adaptor,EU and UK, Unified AP, ROHS, WIFI 6
Zyxel NWA110AX-EU0103F. Maximum data transfer rate: 1775 Mbit/s, Maximum data transfer rate (2.4 GHz): 575 Mbit/s, Maximum data transfer rate (5 GHz): 1200 Mbit/s. Security algorithms: SNMP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA3. AC input voltage: 12 V, Input current: 1.5 A. Placement: Wall, Product colour: , Certification: FCC 15C FCC 15E ETSI EN 300 328 EN 301 893 LP0002 FCC 15B EN 301 489-1 EN 301 489-17 EN55022…. Antenna type: Internal, Antenna gain level (max): 6 dBi
True WiFi 6
The NWA110AX is truly the next generation of wireless (WiFi 6) AP for businesses looking for a most economical upgrade path to 11ax. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO which can’t be found in earlier releases of 802.11ax products.
Built for Superior performance
The NWA110AX boasts an impressive quad-core processor to provide consistently smooth delivery to wireless clients. The NWA110AX is also built with premium power amplifiers and 4G/5G interface filters to deliver superior quality of service that make it one of the best in its class.
Simpler upgrade path
The NWA110AX has been designed to be highly efficient in budget, allowing for an easy upgrade path for those wishing to experience all that WiFi 6 has to offer without the need to upgrade existing + switches
Manage it your way!
As it comes with support for NebulaFlex, Zyxel’s scalable, cloud-based management system, the NWA110AX can be via NCC (Nebula control Center) or simply operate alone (controller less). You can choose the way that is best suited to your needs.
| Weight | 3 kg |
|---|---|
| Receiver sensitivity | -101 dBm |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Weight | 453 g |
| Channel bandwidth | 80 MHz |
| Power over Ethernet (PoE) | Yes |
| AC adapter included | Yes |
| Storage relative humidity (H-H) | 10 – 90% |
| Operating relative humidity (H-H) | 10 – 95% |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -30 – 70 °C |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Security algorithms | SNMP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA3 |
| MAC address filtering | Yes |
| Certification | FCC 15C |
| Antenna gain level (max) | 6 dBi |
| Antenna type | Internal |
| Web-based management | Yes |
| Input current | 1.5 A |
| VLAN support | Yes |
| Height | 39 mm |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
| Depth | 180 mm |
| Width | 180 mm |
| Product colour | White |
| Mounting kit | Yes |
| Placement | Wall |
| Wireless isolation | Yes |
| Auto Wireless Distribution System (WDS) | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Fast roaming | Yes |
| Number of products included | 3 pc(s) |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Band steering | Yes |
| Maximum data transfer rate (2.4 GHz) | 575 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1200 Mbit/s |
| Transmitting power (CE) | 20/22 dBm |
| Transmitting power (FCC) | 23 dBm |
| AC input voltage | 12 V |
| Harmonized System (HS) code | 85176990 |
