Catalyst 9300 48 – port modular uplinks 1G SFP, Network Essentials
Cisco Catalyst C9300-48S-E. Switch type: , Switch layer: /. Basic switching RJ-45 ports type: None. Full duplex. MAC address table: 32000 entries, Switching capacity: 256 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE…. Rack mounting
The Cisco® Catalyst® 9300 Series switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform. Catalyst 9300 Series switches form the foundational building block for Software-Defined Access (SD-Access), Cisco’s lead enterprise architecture. At up to 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density Wi-Fi 6 and 802.11ac Wave2. It sets new maximums for network scale. These switches are also ready for the future, with an x86 CPU architecture and more memory, enabling them to host containers and run third-party applications and scripts natively within the switch.
The Catalyst 9300 Series is designed for Cisco StackWise® technology, providing flexible deployment with support for nonstop forwarding with Stateful Switchover (NSF/SSO), for the most resilient architecture in a stackable (sub-50-ms) solution. The highly resilient and efficient power architecture features Cisco StackPower®, which delivers high-density Plus (+), 60W Cisco Universal (Cisco U) and 90W Cisco U+© ports. The switches are based on the Cisco Unified Access™ Data Plane 2.0 (UADP) 2.0 architecture which not only protects your investment but also allows a larger scale and higher throughput. A modern operating system, Cisco IOS® XE with programmability offers advanced security capabilities and Internet of Things (IoT) convergence.
| Weight | 3 kg |
|---|---|
| Product Condition | New Retail |
| Weight | 7.86 kg |
| Operating altitude | 0 – 3000 m |
| Operating temperature (T-T) | -5 – 40 °C |
| Operating relative humidity (H-H) | 5 – 90% |
| Storage temperature (T-T) | -40 – 70 °C |
| Mean time between failures (MTBF) | 281920 h |
| Number of VLANs | 4000 |
| Jumbo frames support | Yes |
| Product colour | Grey |
| Switching capacity | 256 Gbit/s |
| Full duplex | Yes |
| Access Control List (ACL) | Yes |
| LED indicators | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2/L3 |
| Switch type | Managed |
| MIB support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ap, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3z |
| VLAN support | Yes |
| Depth | 488 mm |
| Height | 43 mm |
| Width | 444 mm |
| Jumbo frames | 9198 |
| SFP module slots quantity | 48 |
| Forwarding rate | 190.47 Mpps |
| DHCP features | DHCP snooping |
| Harmonized System (HS) code | 85176990 |
