CX 6300M, 880 Gbps, 660 Mpps, 48x BaseT RJ-45, 4x 1/10/25/50G SFP, USB C , OOBM, USB A , 44x442x385 mm
HPE Aruba CX 6300M. Switch type: , Switch layer: . Basic switching RJ-45 ports type: , Basic switching RJ-45 ports quantity: 48, USB 2.0 ports quantity: 1, Console port: USB. MAC address table: 32000 entries, Switching capacity: 496 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE…. Rack mounting
The Aruba CX 6300 Switch Series is a modern, flexible and intelligent family of stackable switches ideal for enterprise access, aggregation and core deployments.
A powerful distributed architecture supports scalable, non-blocking performance to future-proof your network for tomorrow’s unpredictable demands. This series has built-in, high-speed uplinks and include models with 24 SFP+ ports and full-density 60W with multi- for a high-performance network.
A cloud-centric design with a fully programmable OS delivers automation and simplicity, including easy-to-use configuration tools for error-free installs. Built-in monitoring and analytics across the network provide operators with immediate troubleshooting and problem resolution insights.
| Weight | 3 kg |
|---|---|
| Number of queues | 8 |
| Product Condition | New Retail |
| Processor frequency | 1800 MHz |
| Flash memory | 32000 MB |
| Internal memory | 8192 MB |
| Weight | 5.51 kg |
| Input current | 3/1.2 A |
| Operating altitude | 0 – 3040 m |
| Storage relative humidity (H-H) | 15 – 90% |
| Operating temperature (T-T) | 0 – 45 °C |
| Operating relative humidity (H-H) | 15 – 95% |
| Storage temperature (T-T) | -40 – 70 °C |
| Non-operating altitude | 0 – 4600 m |
| IP routing | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| Product colour | Black |
| Noise level | 28.7 dB |
| Switching capacity | 496 Gbit/s |
| SSH/SSL support | Yes |
| Access Control List (ACL) | Yes |
| Certification | EN 60950-1:2006; +A11:2009 +A1:2010; +A12:2011 + A2:2013 |
| Quality of Service (QoS) support | Yes |
| System event log | Yes |
| Multicast support | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| 10G support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bt |
| Transmission distance (max) | 10 km |
| USB 2.0 ports quantity | 1 |
| Console port | USB |
| VLAN support | Yes |
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100 – 240 V |
| Depth | 385 mm |
| Height | 44 mm |
| Width | 442 mm |
| Physical stacking (units) | 10 |
| Packet buffer memory | 8 MB |
| Number of multicast groups filtered | 8000 |
| Latency (1 Gbps) | 2.28 µs |
| Latency (10 Gbps) | 1.46 µs |
| Throughput | 369 Mpps |
| Power consumption (max) | 75 W |
| Rack mount kit | Yes |
| SFP module slots quantity | 4 |
| Airflow direction | Front-to-back airflow |
| Routing protocols | OSPF, OSPFv3 |
| Policy-based routing | Yes |
| IGMP entries | 8000 |
| MLD entries | 4000 |
| IPv4 multicast entries | 8000 |
| IPv6 multicast entries | 8000 |
| Configuring Location Settings (CLI) | Yes |
| Number of fans | 2 fan(s) |
| Processor model | ARM Cortex-A72 |
| Built-in processor | Yes |
| DHCP features | DHCP relay, DHCP server |
| Harmonized System (HS) code | 85176990 |
