Socket P (LGA 3647), 8x DIMM DDR4, Intel C622, 2x RJ-45, IPMI LAN, VGA, 2x USB 2.0, 2x USB 3.0, AMI UEFI, 437x178x699 mm
Supermicro SuperStorage Server 5049P-E1CTR36L. Motherboard chipset: Intel C622, Processor socket: LGA 3647 (Socket P), Compatible processor series: Intel® Xeon®. Supported memory types: DDR4-SDRAM, Maximum internal memory: 1000 GB, Maximum RDIMM memory: 192 GB. Storage drive sizes supported: 3.5″, Supported storage drive interfaces: M.2, Serial Attached SCSI (SAS)-3, Serial ATA III, RAID levels: 0, 1, 5, 10. On-board graphics card model: Aspeed AST2500. Copper ethernet cabling technology: 10GBASE-T, LAN controller: Intel® X557, Intel® X722
New generation X11 Supermicro SuperStorage systems support node based deployment strategies where CPU and HDD capacity scale together, or deployments can be expanded using JBODs for improved economy. Low-latency SSD applications, large media files requiring massive capacity and enterprise workloads looking for the highest performance will benefit from Supermicro’s SAS 3.0 (12Gbps) support which provides low-latency and maximum data bandwidth. The Supermicro SuperStorage systems offer a no compromise storage platform with flexible market entry points from 2U, 3U, and 4U form factors using 2.5″ or 3.5″ SSDs/HDDs. SuperStorage servers support up to: 1TB 3DS ECC LRDIMM or 256GB ECC RDIMM memory, PCI-E 3.0 slots, NVMe, flexible networking options such as 10G SFP+, 10GBase-T LAN ports and IPMI 2.0 and KVM with dedicated LAN, and have support for the latest Intel Xeon Scalable processors.
Supermicro SuperStorage solutions present a number of key benefits to customers working with CPU Intensive Storage, Virtual Storage, Single Instance Storage and Data Deduplication, Data Replication and Business Continuity, and Virtual Tape Library customer environments.
| BIOS type | UEFI AMI |
|---|---|
| Compatible processor series | Intel® Xeon® |
| Processor socket | LGA 3647 (Socket P) |
| Hot-swap hard drive bays | Yes |
| Maximum internal memory | 1000 GB |
| Number of DIMM slots | 8 |
| pa_i_ethernetlanrj4_2312_1 | 2 |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Depth | 699 mm |
| Height | 178 mm |
| Weight | 29.7 kg |
| Width | 437 mm |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1200 W |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 10 – 35 °C |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 60 °C |
| LAN controller | Intel® X557, Intel® X722 |
| Product colour | Black |
| RAID levels | 0, 1, 5, 10 |
| LED indicators | HDD, Heating, Network, Power, Power fail |
| PCI Express x16 slots | 1 |
| PCI Express x4 slots | 1 |
| PCI Express x8 slots | 2 |
| Number of processors supported | 1 |
| Motherboard chipset | Intel C622 |
| Supported RDIMM clock speeds | 2133,2400,2666 MHz |
| Supported memory types | DDR4-SDRAM |
| Maximum RDIMM memory | 192 GB |
| IPMI LAN (RJ-45) port | Yes |
| Copper ethernet cabling technology | 10GBASE-T |
| PC health monitoring | CPU, Fan, Temperature |
| PCI Express slots version | 2.0, 3.0 |
| Chassis type | Rack (4U) |
| Backplanes support | Yes |
| Ethernet LAN | Yes |
| On-board graphics card model | Aspeed AST2500 |
| Number of redundant power supplies installed | 2 |
| Fan diameter | 8 cm |
| On/off switch | Yes |
| Number of fans | 7 fan(s) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Number of 3.5" bays | 12 |
| Supported storage drive interfaces | M.2, Serial Attached SCSI (SAS)-3, Serial ATA III |
| Package weight | 46.4 kg |
| Storage drive sizes supported | 3.5" |
| Harmonized System (HS) code | 84714100 |
| Sustainability certificates | RoHS |
