SSG-6047R-E1R72L , Intel Xeon E5-2600, 16x 240-pin DDR3 DIMM sockets, Intel C602J Chipset, 4x PCI-E 3.0 x8 slots, 72x 3.5″ SAS2/SATA3 in 36x Hot-swap, 128Mb SPI Flash EEPROM with AMI BIOS
Supermicro SuperStorage Server 6047R-E1R72L. Motherboard chipset: Intel® C602J, Processor socket: LGA 2011 (Socket R), Processor family: Intel. Supported memory types: DDR3-SDRAM, Supported DIMM module capacities: 16GB, 1GB, 2GB, 32GB, 4GB, 8GB, Maximum RDIMM memory: 512 GB. Storage drive sizes supported: 3.5″, Supported storage drive interfaces: Serial ATA II, Serial ATA III, RAID levels: 0, 1, 5, 10. On-board graphics card model: Matrox G200. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10GBASE-T
1. Intel® Xeon® processor E5-2600
family; QPI up to 8GT/s
2. Up to 512GB DDR3 1600MHz ECC
Registered DIMM; 16x DIMM sockets
3. 4x PCI-E 3.0 x8 slots
4. Intel® i350 GbE Controller; 4x ports
5. 72x 3.5″ SAS2/SATA3 HDDs in 36x
(24 front + 12 rear) Hot-swap Drive
Bays (2x HDD per bay w/ LEDs for
each drive)
6. Chassis remains securely mounted in
rack during HDD replacement, safer
and more reliable than top loading
solutions
7. 2x 2.5″ Internal drive bays
8. 3x IT mode SAS2 Storage Controllers
(LSI 2308)
9. Server remote management: IPMI 2.0
/ KVM over LAN / Media over LAN
10. 7x Heavy duty PWM fans
11. Triple 1280W (2+1) Redundant Digital
Platinum Level (95%) PS
2x PWS-2K02P-1R Optional
| BIOS memory size | 128 Mbit |
|---|---|
| BIOS type | AMI |
| Compatible processor series | Intel® Xeon® |
| Processor family | Intel |
| Processor socket | LGA 2011 (Socket R) |
| Hot-swap hard drive bays | Yes |
| ECC | Yes |
| Number of DIMM slots | 16 |
| pa_i_ethernetlanrj4_2312_1 | 4 |
| USB 2.0 ports quantity | 9 |
| VGA (D-Sub) ports quantity | 1 |
| Depth | 889 mm |
| Height | 178 mm |
| Weight | 30.4 kg |
| Width | 437 mm |
| Power supply | 1280 W |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | 10 – 35 °C |
| Product colour | Black |
| RAID levels | 0, 1, 5, 10 |
| PCI Express x8 slots | 4 |
| Memory voltage | 1.35,1.5 V |
| System bus rate | 8 GT/s |
| Intel Xeon series | E5-2600 |
| Motherboard chipset | Intel® C602J |
| Memory form factor | 240-pin DIMM |
| Supported RDIMM clock speeds | 800,1066,1333,1600 MHz |
| Supported memory types | DDR3-SDRAM |
| Supported UDIMM clock speeds | 800,1066,1333,1600 MHz |
| Supported DIMM module capacities | 16GB, 1GB, 2GB, 32GB, 4GB, 8GB |
| Maximum UDIMM memory | 128 GB |
| Maximum RDIMM memory | 512 GB |
| IPMI LAN (RJ-45) port | Yes |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10GBASE-T |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power LED | Yes |
| PCI Express slots version | 3.0 |
| Chassis type | Rack (4U) |
| Ethernet LAN | Yes |
| On-board graphics card model | Matrox G200 |
| On/off switch | Yes |
| System bus type | QuickPath Interconnect (QPI) |
| Maximum cache | 20 MB |
| Number of SATA II connectors | 4 |
| Number of SATA III connectors | 2 |
| BIOS features | APM 1.2, PCI 2.2, Plug & Play, SMBIOS 2.3, UEFI |
| Number of storage drives supported | 72 |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| ACPI version | 2.0 |
| Storage drive sizes supported | 3.5" |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Number of SAS ports | 8 |
| Sustainability certificates | RoHS |
