The EX2300-24T switch is an efficient and compact solution, offering 24 ports for small to medium-sized network deployments. It is designed to provide high performance and reliability, ideal for access and aggregation use cases in enterprise environments.
New Retail Juniper from a Certified Partner gaurantees that your product has:
• Access to the Latest Firmware and Features
• Comprehensive Juniper Care Service & Support
• Protected by a Full Juniper Networks Warranty
| Weight | 3 kg |
|---|---|
| Electromagnetic compatibility | FCC 47CFR 15 A, EN 55022 A, ICES-003 A, VCCI A, AS/NZS CISPR 22 A, CISPR 22 A, EN 55024, EN 300386, CE |
| Product Condition | New Retail |
| Processor frequency | 1250 MHz |
| Memory type | DRAM |
| Flash memory | 2000 MB |
| Internal memory | 2000 MB |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
| Weight | 3.29 kg |
| Operating altitude | 0 – 3962 m |
| Storage relative humidity (H-H) | 0 – 95% |
| Operating temperature (T-T) | 0 – 45 °C |
| Operating relative humidity (H-H) | 10 – 85% |
| Storage temperature (T-T) | -40 – 70 °C |
| Non-operating altitude | 0 – 4572 m |
| Number of VLANs | 4093 |
| IP routing | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| IGMP snooping | Yes |
| Product colour | Grey |
| Noise level | 34.2 dB |
| Switching capacity | 128 Gbit/s |
| Security algorithms | 802.1x RADIUS, HTTPS, SNMP, SSH-2 |
| Access Control List (ACL) | Yes |
| Certification | ROHS |
| Safety | UL-UL60950-1, C-UL CAN/CSA 22.2 #.60950-1, TUV/GS EN 60950-1, CB-IEC60950-1, EN 60825-1 |
| Quality of Service (QoS) support | Yes |
| System event log | Yes |
| Multicast support | Yes |
| Web-based management | Yes |
| Switch layer | L2/L3 |
| Switch type | Managed |
| MIB support | RFC 1155, RFC 1157, RFC 1212, RFC 1213, RFC 1215, RFC 1493, RFC 1643, RFC 1724, RFC 1905, RFC 1981, RFC 2011, RFC 2012, RFC 2013, RFC 2096, RFC 2287, RFC 2460, RFC 2464, RFC 2570-2575, RFC 2576, RFC 2578, RFC 2579, RFC 2665, RFC 2819, RFC 2863, RFC 2922, RFC 2925, RFC 3413, RFC 3414, RFC 3415, RFC 3484, RFC 3621, RFC 4188, RFC 4213, RFC 4291, RFC 4363, RFC 4443, RFC 4861, RFC 4862 |
| 10G support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z |
| Fiber ethernet cabling technology | 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX |
| VLAN support | Yes |
| Depth | 259 mm |
| Height | 44.5 mm |
| Width | 441.9 mm |
| Throughput | 95 Mpps |
| Power consumption (max) | 55 W |
| Jumbo frames | 9216 |
| Access Control List (ACL) rules | 1500 |
| ARP inspection | Yes |
| SFP+ module slots quantity | 4 |
| Built-in processor | Yes |
| DHCP features | DHCP server, DHCP client |
| Virtual LAN features | Private VLAN, Tagged VLAN, Port-based VLAN |
| Harmonized System (HS) code | 85176990 |
