Dual Socket R3 (LGA 2011), 24 DDR4 DIMM, 48x 2.5″ SATAIII/SAS3, Intel C612, 3x USB 3.0, VGA, 2U, 437x89x767 mm
Supermicro SuperStorage Server 2028R-E1CR48L. Motherboard chipset: Intel® C612, Processor socket: LGA 2011 (Socket R), System bus type: QuickPath Interconnect (QPI). Supported memory types: DDR4-SDRAM, Supported DIMM module capacities: 4GB, 8GB, 16GB, 32GB, 64GB, Maximum internal memory: 3000 GB. Storage drive sizes supported: 2.5″, Supported storage drive interfaces: Serial Attached SCSI (SAS)-3, Serial ATA III, RAID levels: 0, 1, 5, 10. On-board graphics card model: Aspeed AST2400. BIOS type: EEPROM, BIOS memory size: 128 Mbit, BIOS features: APM 1.2, PCI 2.2, SMBIOS 2.3, UEFI
Supermicro’s new Simply Double 2U SuperStorage systems include twice the number of hot-swap drive bays as 2U industry standard systems, thus offering up to twice the storage capacity and IOPS in the same amount of space. The additional drive bays are arrayed in a patented Riser Bay that is located on the top of the Simply Double systems for easy access and servicing. With twice the storage density, customers can greatly improve the price/performance of their storage deployments to maximize ROI.
The Supermicro 2U Simply Double SuperStorage systems are available in server or JBOD models that offer either 2.5″ or 3.5″ drive bays, and that also support All Flash NVMe SSDs or SAS 3.0 HDDs. Additional value-added features include an additional two rear hot-swap drive bays, 3 PCI-E 3.0 slots, redundant Titanium Level (96%+) high-efficiency power supplies, and support for the latest Intel® Xeon® processor E5-2600 v4/v3 family. This broad and feature rich product line allows customers to select the Simply Double solution that is optimized for their specific requirements, from IOPS intensive applications to deployments that require the highest storage capacity.
| BIOS memory size | 128 Mbit |
|---|---|
| BIOS type | EEPROM |
| Compatible processor series | Intel® Xeon® |
| Processor socket | LGA 2011 (Socket R) |
| Hot-swap hard drive bays | Yes |
| ECC | Yes |
| Maximum internal memory | 3000 GB |
| Number of DIMM slots | 24 |
| VGA (D-Sub) ports quantity | 1 |
| Depth | 767 mm |
| Height | 89 mm |
| Width | 437 mm |
| Redundant power supply (RPS) support | Yes |
| Power supply | 1600 W |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 10 – 35 °C |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 70 °C |
| Product colour | Black, Grey |
| RAID levels | 0, 1, 5, 10 |
| LED indicators | HDD, Heating, Network, Power, Power fail |
| Number of processors supported | 2 |
| Intel Xeon series | E5-2600 |
| Motherboard chipset | Intel® C612 |
| Memory form factor | 288-pin DIMM |
| Supported RDIMM clock speeds | 1600,1866,2133,2400 MHz |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 4GB, 8GB, 16GB, 32GB, 64GB |
| Chassis type | Rack (2U) |
| On-board graphics card model | Aspeed AST2400 |
| Number of redundant power supplies installed | 2 |
| Fan diameter | 8 cm |
| On/off switch | Yes |
| Number of fans | 5 fan(s) |
| System bus type | QuickPath Interconnect (QPI) |
| Maximum cache | 55 MB |
| Memory bus | 72 bit |
| BIOS features | APM 1.2, PCI 2.2, SMBIOS 2.3, UEFI |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Number of storage drives supported | 48 |
| Supported storage drive interfaces | Serial Attached SCSI (SAS)-3, Serial ATA III |
| ACPI version | 2.0 |
| Storage drive sizes supported | 2.5" |
| Sustainability certificates | RoHS |
